APPLICATIONS
- For sewing medium to medium heavy-weight fabrics. leather, canvas, vinyl, synthetics and various coated and laminated materials
- Designed for sewing operations which require decorative or functional angular stitching such as collars, pockets, shoe uppers, auto, boat and furniture upholstery, slacks, shirts, etc.
- Designed for stitching such products as overalls. raincoats. luggage, travel-ware accessories, bags, umbrellas, awnings, covers, tarpaulins, tents, wearing apparel, outdoor clothing, underwear, etc.
- General/parallel two-needle stitching with split bar for making even angle turns.
- Suitable for stitching uneven, hollow, tubular and curved articles
FEATURES
- Compound feed, walking foot mechanism assures perfect feeding of sewing material
- Large hooks and bobbin cases with their own thread take-up mechanism assure uniform and perfect stitching with minimal bobbin changes
- Easy operation of disengage-able right and left needle bars by use of finger-touch lever
- Centra-Lube~ semi-automatic lubrication system
- Oil fed take-up
- Stitches per minute - 2200
- Reverse stitching
- Various gauge sets available
- Safety clutch protects the hooks from being damaged
SPECIFICATIONS
| Number of Needles | 2 (Double) |
| Feeding Mechanism | Walking Foot |
| Workspace | Standard Workspace |
| Standard or Full Function | Standard Functions |
| Speed, Max (S.P.M.) | 2200 |
| Clearance Under Presser Foot | 11/32" (8.5mm) |
| Stitch Length | 5 s.p.i. (5mm) |
| Needle | 135x17 |
| Bed Size | 7"x20 3/8" (177mm x 518mm) |
| Stitch Type | 301 |
| Hook | 14005 |
| Post Height | 7" (178mm) |
| Work Surface | 2 1/8" x 4" (54 x 101mm) |
